Pre Painted Galvanized Sheet - - HAIXING
prepainted galvalume steel coil ppgl are high-quality steel sheets coated with vibrant colors and protective layers for enhanced durability, corrosion resistance, and visual appeal. Available in various thicknesses, finishes, and colors, they are widely used in construction, roofing, home appliances, and automotive manufacturing. These coils are lightweight, easy to process, and offer excellent performance in harsh environments. Designed to meet international standards, they provide a cost-effective solution for applications requiring both functionality and aesthetics. Contact us for tailored specifications and solutions.
| Product Name: | PPGL |
| Production process: | material selection, surface treatment, coating application, baking, quality inspection, and packaging |
| Thickness | 0.3 - 1.0mm |
| Zinc Coating: | AZ 15-150 g/m2 |
| Range of paint film thickness | 16μm/6μm |
| Color | Customer's reqirements (refer RAL color series ) |
| Fading time | 8-25Years, According to the different color retention periods of paint quality |
| Place of Origin: | Tianjin, China |
| Standard: | AISI, ASTM, BS, DIN, GB, JIS |
| Grade | SGLCC, DX51D, A653, SGLCH, Q235B |
| Hardness | HRB60- HRB90 ， according customer requirement |
| MOQ | 4 ton, Suggest purchasing the entire roll |
| Delivery Time: | Withih 20-50days after signing contract |
| Coil weight | 2-5 Tons/coil |
| Packing | Standard seaworthy export packing:3 layers of packing, inside is metal pail, water plastic film is in the middle and outside GI steel sheet to be covered by steel strips with lock, wit inner coil sleeve. |
| Width: | 760mm-1250mm, according to customer's requirement |
| Coil ID | 508/610mm |
| Port Of Shipment | Tianjin, China |
Company Advantages
· HAIXING pre painted galvanized sheet is produced under standard 5S operating environment.
· The performance index of pre painted galvanized sheet is in the domestic leading position.
· As we adhere to continuous innovation, the product will be given more advantages and will be more widely used in the future.
Company Features
· TIANJIN HAIXING IMP.& EXP. CO., LTD, a specialist manufacturer and producer of pre painted galvanized sheet, has gained recognization in the domestic markets.
· We have introduced some advanced production facilities. These facilities are equipped with modern technologies, which can ensure greater productivity and more flexible delivery times.
· During the developing process of HAIXING, we will be earnest to undertake the responsibility as a leader in pre painted galvanized sheet industry. Inquire online!
Application of the Product
The pre painted galvanized sheet produced by HAIXING is very popular in the market and is widely used in industry.
HAIXING is dedicated to solving your problems and providing you with one-stop and comprehensive solutions.
