Solar Bracket Roll Forming Machine | PV Mounting Production Line
Voltage: 380V（Customizable）
Productivity: 15-20m/min
Warranty: 2 years
Rolling thinckness: 2.0-3.0mm
Main motor power: 18.5*2
Control system: PLC(imported Brand)
Cutting blade material: Cr 12 Steel
Shaft material: 45# Steel
Suitable to process: Galvanized coils
Usage: Customizable
Roll forming machine for solar structure Product description
The global shift toward renewable energy has placed solar power at the forefront of sustainable development. For manufacturers specializing in photovoltaic (PV) mounting systems, production efficiency, customization, and consistent quality are critical. Our company, a trusted manufacturer of cold roll forming machinery, is proud to introduce our fully automated roll forming machine for solar structure Line. This integrated solution is specifically engineered to produce high-strength, precision-formed solar brackets with remarkable speed and accuracy, supporting the growing demands of the solar industry worldwide.
| Product Name | roll forming machine for solar structure |
| Punching | Servo non-stop punching |
| Structure | 500H Beam |
| Main motor power | Dual 18.5KW motors + K97 reducer |
| Hydraulic components | 11KW×2 pump station 1 unit (for punching) 4KW pump station 1 unit (for cutting) 3KW pump station 1 unit (for pressing) |
| Cutting type | Tracking Cut |
| Produce speed | 15-20 m/min |
| Shaft material | 45# steel, quenched and tempered |
| Brand of electrical control cabinet | Delta or customized according to customer requirements |
| Touch screen/inverter | Delta or customized according to customer requirements |
| Rolling materials | High quality CR12 quenching |
| Cutting blade material | Cr12, treatment off 58 ℃ -60 ℃ |
| Roller diameter | Φ80mm |
| Voltage | 380v 50hz 3p be customized |
| Feeding thickness | 2.0-3.0mm |
| Rows | The number of rows is usually 24-26, and the 3mm thick 41*72 model may have 28 rows. |
